Tektronix VX4802 Arbitrary Waveform Generator, High-Frequency Signal Source

Description

Frequency Range:Up to 500 MHz

Waveform Types:Sine, Square, Triangle, Pulse, Noise, Arbitrary

Amplitude Range:200 mVpp to 10 Vpp

Resolution:14-bit

Sampling Rate:2 GSa/s

Output Impedance:50 Ohms

Interface:USB, LAN, GPIB

Dimensions:178 x 339 x 71 mm

Weight:3.5 kg

    The Tektronix VX4802 is built with precision engineering, ensuring reliable performance under demanding conditions. Its robust design includes a user-friendly interface that simplifies complex operations.

    Equipped with a broad range of waveform types, the VX4802 supports Sine, Square, Triangle, Ramp, Pulse, Noise, and Arbitrary waveforms, providing versatility in various industrial applications.

    With a 14-bit vertical resolution and sampling rate of up to 250 MSa/s, this generator delivers exceptional accuracy and detail in its outputs, making it perfect for high-fidelity signal generation.

    The phase shift capability allows for fine-tuning of signal timing, ensuring precise synchronization across multiple channels or systems.

    The VX4802 comes with an intuitive control panel and comprehensive software support, enabling users to easily configure and monitor settings from a connected PC or directly on the device.
