SMC MY1B50-1000: Pneumatic Actuator – Precision Control Module

Description

Model:MY1B50-1000

Series:MY

Bore Diameter:50 mm

Stroke Length:1000 mm

Operating Pressure Range:0.1 – 0.8 MPa

Maximum Output Force:500 N

Repeatability:±0.02 mm

Speed Range:0.01 – 0.1 m/s

Weight:Approx. 2.5 kg

Material:Aluminum alloy with steel piston rod

Coating:Anti-corrosion treatment

Operating Temperature:-20°C to +60°C

    The SMC MY1B50-1000 Advanced Motion Control Module is engineered for high-precision motion control in a wide range of industrial applications, from robotics to packaging machines. Its robust design ensures reliable performance under demanding conditions.

    This module supports both digital and analog control signals, allowing seamless integration with existing systems. It boasts a response time of less than 1 millisecond, ensuring swift and accurate control of machine movements.

    Featuring a position accuracy of ±0.01mm, the MY1B50-1000 provides unparalleled precision for tasks requiring fine-tuned control. The unit is built to withstand temperatures ranging from -20°C to +85°C, making it ideal for use in diverse environments.

    With its IP65 protection rating, the module is dust-tight and protected against water jets, enhancing durability and reliability in harsh industrial settings. The compact size and lightweight design make installation straightforward, without compromising on performance.

    Designed for ease of use, the SMC MY1B50-1000 includes comprehensive documentation and technical support. Whether you’re upgrading an existing system or building a new one, this advanced motion control module offers the precision and flexibility you need.
