Description
# of Digital/Switch Inputs:6 optically isolated
Ambient Humidity Maximum:Up to 95% non-condensing
Control Power nominal:20 VA
Control Power maximum:65 VA
Dimensions:approx. 11.5 in H x 5.5 in W x 8.5 in L
Fuse:3.15 A H 250 V
Maximum Altitude:2000 m (max)
Phase Current Inputs:1 A and 5 A secondary
Recordable Events:last 512 events
Communications:RS232 port, RS485 port
Waveform Capture Length:3 buffers containing 16 cycles of all current and voltage channels
Weight:approx. 10 lbs
Enhance your motor management with the GE 369-HI-R-M-0-D-0-E, a robust and reliable relay designed specifically for motor protection and monitoring.
Featuring advanced metering capabilities, this relay captures waveforms, logs events, and provides data logging, which are crucial for understanding system performance and predicting failures.
It supports adjustable settings like motor inrush current and cooling rates, making it highly customizable to fit various industrial applications.
With its comprehensive metering package, it offers invaluable insights into the operational status of motors and associated equipment, enabling proactive maintenance and reducing downtime.
The GE 369-HI-R-M-0-D-0-E is easy to install and configure, making it a valuable addition to any industrial control system.
