Eaton MTL 8507-BI-DP Digital Signal Isolator Module

Description

Manufacturer:Eaton

Model:MTL 8507-BI-DP

Function:Safety Barrier

Input Voltage Range:24-240 VAC/VDC

Output Voltage Range:24 VDC

Current Rating:250 mA

Protection Rating:IP20

Isolation Voltage:2500 VAC

Dimensions:135 mm x 110 mm x 70 mm

Weight:0.5 kg

    The Eaton MTL 8507-BI-DP Isolating Signal Conditioner is an essential component for industrial automation systems. It provides robust isolation between the field devices and control systems, ensuring accurate signal transmission even in challenging environments. Designed with precision engineering, this signal conditioner offers high accuracy (+/- 0.1% of span) and operates within a wide temperature range (-40°C to +85°C). The IP65 environmental protection ensures durability against dust and water ingress. With a compact design measuring 140 mm x 100 mm x 50 mm, it easily integrates into existing control systems. The Eaton MTL 8507-BI-DP supports input and output signal ranges of 0-20 mA and 4-20 mA, making it compatible with a variety of field devices. Additionally, it operates at a supply voltage of 24 VDC, providing reliable power for industrial applications. The isolation voltage of 1000 VDC ensures safe operation, protecting both personnel and equipment from electrical hazards. Its weight of approximately 0.5 kg makes it easy to install and maintain.
